Rebar Placing Drawings
Our rebar placing drawings are developed by experienced civil engineers with a strong focus on precision and compliance with ACI and CRSI standards. Leveraging Rebar CAD, we produce high-quality shop drawings in PDF and DWG formats to support seamless construction workflows.
Fabrication & Placer Friendly
Unconfined bars are systematically grouped to reduce bar marks and improve clarity, with placer-friendly layouts that enable efficient fabrication, cost-effective placement, and on-time project delivery.
Clear & Easy to Understand
Each drawing sheet is accompanied by a dedicated bar bending schedule to ensure clear interpretation. Detailed cross-sections and enlarged views are provided for congested reinforcement areas, eliminating ambiguity during fabrication and placement.
Three-Level Quality Assurance
All placing drawings undergo a strict three-level review process:
- Level 1 – Self-Check: Initial verification by the drafting engineer
- Level 2 – Quality Control: QA/QC review for accuracy and compliance
- Level 3 – Project Manager Review: Final approval as per project standards
This structured process ensures the delivery of reliable, high-quality drawings that support on-time, cost-effective project execution.
